Code Coverage for Zig

Ryan Liptak
・4 min read

Despite the Zig compiler not having built-in support for generating code coverage information, it is still possible to generate it (on Linux at least). There might be other possibilities, but this post will focus on two possible tools:

  • kcov, which adds breakpoints on each line of code to generate coverage information
  • grindcov, which uses Valgrind's Callgrind tool to instrument code at runtime to generate coverage information

(note: other tools that similarily don't rely on compile-time instrumentation can likely be used/integrated in the same way as detailed in this post)


Coverage for compiled executables

This is the simplest case. As long as the executable is compiled with debug information, then it's as simple as running the executable with the chosen coverage tool. For example, if you had a main.zig consisting of:

const std = @import("std");

pub fn main() !void {
    var args_it = std.process.args();
    std.debug.assert(args_it.skip());
    const arg = args_it.nextPosix() orelse "goodbye";

    if (std.mem.eql(u8, arg, "hello")) {
        std.debug.print("hello!\n", .{});
    } else {
        std.debug.print("goodbye!\n", .{});
    }
}
Enter fullscreen mode Exit fullscreen mode

Then generating coverage information would be done by:

$ zig build-exe main.zig
# with kcov
$ kcov kcov-output ./main hello
hello!
# or with grindcov
$ grindcov -- ./main hello
Results for 1 source files generated in directory 'coverage'

File           Covered LOC Executable LOC Coverage
-------------- ----------- -------------- --------
main.zig       6           7                85.71%
-------------- ----------- -------------- --------
Total          6           7                85.71%
Enter fullscreen mode Exit fullscreen mode

Coverage for tests using zig test

Tests in Zig are handled a bit differently, since the actual test binary is considered temporary and only lives in zig-cache. There are two options here:

The first (and more manual) option is to use the --enable-cache flag to get the path to the directory that the test binary is created in, and then use that to construct the arguments to pass to the coverage tool.

  • The test executable itself is named test
  • To run the test executable you need to pass the path to the zig binary to it

Using this option would therefore look something like this:

$ zig test test.zig --enable-cache
zig-cache/o/ac1029e39986cc8cf3d732585f5a8060
All 1 tests passed.
# with kcov
$ kcov kcov-output ./zig-cache/o/ac1029e39986cc8cf3d732585f5a8060/test zig
# or with grindcov
$ grindcov -- ./zig-cache/o/ac1029e39986cc8cf3d732585f5a8060/test zig
Enter fullscreen mode Exit fullscreen mode

The second (and more preferred) option is to use the --test-cmd and --test-cmd-bin options to set a coverage generator as the 'test executor'. With this, Zig handles the passing of the necessary arguments to the coverage tool for you.

--test-cmd-bin is necessary to tell zig to append the test binary path to the executor's arguments

Using this option would instead look like this:

# with kcov
$ zig test test.zig --test-cmd kcov --test-cmd kcov-output --test-cmd-bin
# or with grindcov
$ zig test test.zig --test-cmd grindcov --test-cmd -- --test-cmd-bin
Enter fullscreen mode Exit fullscreen mode

Integrating test coverage with build.zig

To generate coverage for a test step in build.zig, the idea is the same as with zig test but instead of passing --test-cmd yourself, you can use LibExeObjStep.setExecCmd to make the Zig build system pass those arguments to zig test for you.

For example, if you had a test step in your build.zig like:

var tests = b.addTest("test.zig");

const test_step = b.step("test", "Run all tests");
test_step.dependOn(&tests.step);
Enter fullscreen mode Exit fullscreen mode

then you could add an option to run the tests with a coverage tool by updating the code to:

const coverage = b.option(bool, "test-coverage", "Generate test coverage") orelse false;

var tests = b.addTest("test.zig");

if (coverage) {
    // with kcov
    tests.setExecCmd(&[_]?[]const u8{
        "kcov",
        //"--path-strip-level=3", // any kcov flags can be specified here
        "kcov-output", // output dir for kcov
        null, // to get zig to use the --test-cmd-bin flag
    });

    // or with grindcov
    //tests.setExecCmd(&[_]?[]const u8{
    //    "grindcov",
    //    //"--keep-out-file", // any grindcov flags can be specified here
    //    "--",
    //    null, // to get zig to use the --test-cmd-bin flag
    //});
}

const test_step = b.step("test", "Run all tests");
test_step.dependOn(&tests.step);
Enter fullscreen mode Exit fullscreen mode

And test coverage information could then be generated by doing:

zig build test -Dtest-coverage
Enter fullscreen mode Exit fullscreen mode

A caveat worth noting

Since the Zig compiler only compiles functions that are actually called/referenced, completely unused functions don’t contribute to the ‘executable lines’ total in either tools' coverage results. Because of this, a file with one used function and many unused functions could potentially show up as 100% covered.

In other words, the results are only indicative of the coverage of used functions.


kcov vs grindcov, which should you use?

grindcov has a lot of shortcomings that kcov doesn't, so kcov is almost certainly the better option for most use cases (unfortunately, I wasn't aware of kcov when I was writing grindcov).

kcov is more mature, has support for more use cases (like dynamic libraries), and is way faster to execute.

To give an idea of the speed difference, when generating coverage for the Zig standard library tests for a single target:

  • Running normally took ~5 seconds
  • Running with kcov took ~9 seconds
  • Running with grindcov took ~2 minutes (and roughly the same amount of time was taken when running with valgrind --tool=callgrind directly, so this may not be improvable without patches to callgrind)

However, if you have a straightforward use case, execution speed isn't too important, and you prefer the output format of grindcov's results, then grindcov would be a fine choice as well.
